Thermo-Trex® Reflective Fiberglass Ultra-Sleeve High Temperature Sleeving

Reflective Fiberglass Ultra-Sleeve High Temperature Sleeving is a protective sleeve that is ideal for radiant heat applications. This Ultra-Sleeve offers flame, moisture and chemical resistance with outstanding flexibility, toughness and tensile strength.

Features

Texturized Glass Fiber Inner Sleeve

Finer strands mean more flexibility. Higher density of fibers per square inch increases protection of cable.

Aluminized Heat Seal Film Outer Sleeve

Protects cables by providing a highly reflective aluminum laminate foil barrier to radiant heat.

High Temperature Properties

Suitable for continuous use at 204°C and intermittent use up to 538°C. Offers superior protection for cables, assemblies, or hoses, minimizing the effect of radiant heat energy transfer through the glass fiber base.

Fray Resistant Design

Will not unravel or fray when exposed to constant flexing or movement.

Available in Multiple Diameters

Allows for selection of the right size sleeve for the application. Protects most cable & hose sizes.

Resources

Specsheets

Product Overview

Ratings / Characteristics

  • RoHS Compliant

  • Continuous Temperature up to 400°F (204°C)

  • Intermittent Temperatures up to 1000°F (538°C)

  • Flame Resistance: Good

  • Weld Spatter Resistance: Good

  • Molten Splash Resistance: Good

  • Flexibility: Outstanding

  • Abrasion Resistance: Outstanding

  • Water and Oil Resistance: Outstanding

Applications

heat-icon

High Temperature

flexing-icon

Flexing

abrasions-icon

Abrasion

Part Numbers

Part No. INNER DIAMETER
inches
49401 0.5
49402 0.75
49403 1
49404 1.5
49405 2
49406 2.5
49407 3
49408 3.5
49409 4
