Quick-Connex M12 DC Micro Cordsets make replacment of electrical and electronic control devices quick and simple. Cordsets made with Trex-Onics® Control Cable are designed for high cycle, constant motion applications and provides excellent defense against impact, cutting, abrasion, oil and chemicals. Solid brass contact pins are nickel coated and gold plated to resist corrosion and ensures electrical integrity in both AC and DC low voltage applications.
Designed for high cycle, constant motion applications. Provides excellent defense against impact, cutting, abrasion, oil and chemicals.
Compatible with all industry standards for DC applications. Provides a superior seal against fluid and dust penetration.
Resists corrosion. Ensures electrical integrity in DC applications.
Protects the insert, pins and sleeves from impact and abuse.
Seals out oil, chemicals and other contaminants. Provides a positive seal on mated components.
Ensures a 100% bond between head and cord. Eliminates glues and bonding materials that break down and leak over time, resulting in loss of signal and continuity.
Industry standard M12 one keyway design provides rapid and secure connection.
| Product No. | Conductor Size (AWG) | Conductor/Pole Count | Meters | Feet | Description | Shielding Type |
|---|---|---|---|---|---|---|
| 64203 | 18 AWG | 2 | 1 | 3.27 | Straight Female Plug | No Shielding |
| 64206 | 18 AWG | 2 | 2 | 6.56 | Straight Female Plug | No Shielding |
| 64212 | 18 AWG | 2 | 4 | 13.08 | Straight Female Plug | No Shielding |
| 64220 | 18 AWG | 2 | 6 | 19.67 | Straight Female Plug | No Shielding |
| CF12C16M010 | 18 AWG | 2 | 10 | 32.8 | Straight Female Plug | No Shielding |
| 69203 | 18 AWG | 2 | 1 | 3.27 | 90° Female Plug | No Shielding |
| 69206 | 18 AWG | 2 | 2 | 6.56 | 90° Female Plug | No Shielding |
| 69212 | 18 AWG | 2 | 4 | 13.08 | 90° Female Plug | No Shielding |
| 69220 | 18 AWG | 2 | 6 | 19.67 | 90° Female Plug | No Shielding |
| CF22E16A020 | 18 AWG | 2 | 0.5 | 1.64 | M/F Extension Set | No Shielding |
| 63223 | 18 AWG | 2 | 1 | 3.27 | M/F Extension Set | No Shielding |
| 63226 | 18 AWG | 2 | 2 | 6.56 | M/F Extension Set | No Shielding |
| CF22E16M003 | 18 AWG | 2 | 3 | 9.84 | M/F Extension Set | No Shielding |
| 63232 | 18 AWG | 2 | 4 | 13.08 | M/F Extension Set | No Shielding |
| CF22E16M005 | 18 AWG | 2 | 5 | 16 | M/F Extension Set | No Shielding |
| 63240 | 18 AWG | 2 | 6 | 19.67 | M/F Extension Set | No Shielding |
| CF22E16M010 | 18 AWG | 2 | 10 | 32.8 | M/F Extension Set | No Shielding |
| 64303 | 18 AWG | 3 | 1 | 3.27 | Straight Female Plug | No Shielding |
| 64306 | 18 AWG | 3 | 2 | 6.56 | Straight Female Plug | No Shielding |
| 64312 | 18 AWG | 3 | 4 | 13.08 | Straight Female Plug | No Shielding |
| 64320 | 18 AWG | 3 | 6 | 19.67 | Straight Female Plug | No Shielding |
| CF13C17M010 | 18 AWG | 3 | 10 | 32.8 | Straight Female Plug | No Shielding |
| CF13C17M015 | 18 AWG | 3 | 15 | 49.21 | Straight Female Plug | No Shielding |
| CF13C17M020 | 18 AWG | 3 | 20 | 65.61 | Straight Female Plug | No Shielding |
| CF13C17M025 | 18 AWG | 3 | 25 | 82.02 | Straight Female Plug | No Shielding |
| CF13C17M030 | 18 AWG | 3 | 30 | 98.42 | Straight Female Plug | No Shielding |
| 69303 | 18 AWG | 3 | 1 | 3.27 | 90° Female Plug | No Shielding |
| 69306 | 18 AWG | 3 | 2 | 6.56 | 90° Female Plug | No Shielding |
| 69312 | 18 AWG | 3 | 4 | 13.08 | 90° Female Plug | No Shielding |
| 69320 | 18 AWG | 3 | 6 | 19.67 | 90° Female Plug | No Shielding |
| CF13D17M010 | 18 AWG | 3 | 10 | 32.8 | 90° Female Plug | No Shielding |
| CF13D17M015 | 18 AWG | 3 | 15 | 49.21 | 90° Female Plug | No Shielding |
| CF13D17M020 | 18 AWG | 3 | 20 | 65.61 | 90° Female Plug | No Shielding |
| CF13D17M025 | 18 AWG | 3 | 25 | 82.02 | 90° Female Plug | No Shielding |
| CF13D17M030 | 18 AWG | 3 | 30 | 98.42 | 90° Female Plug | No Shielding |
| CF23E17A020 | 18 AWG | 3 | 0.5 | 1.64 | M/F Extension Set | No Shielding |
| 63323 | 18 AWG | 3 | 1 | 3.27 | M/F Extension Set | No Shielding |
| 63326 | 18 AWG | 3 | 2 | 6.56 | M/F Extension Set | No Shielding |
| CF23E17M003 | 18 AWG | 3 | 3 | 9.84 | M/F Extension Set | No Shielding |
| 63332 | 18 AWG | 3 | 4 | 13.08 | M/F Extension Set | No Shielding |
| CF23E17M005 | 18 AWG | 3 | 5 | 16 | M/F Extension Set | No Shielding |
| 63340 | 18 AWG | 3 | 6 | 19.67 | M/F Extension Set | No Shielding |
| CF23E17M010 | 18 AWG | 3 | 10 | 32.8 | M/F Extension Set | No Shielding |
| CF23E17M015 | 18 AWG | 3 | 15 | 49.21 | M/F Extension Set | No Shielding |
| CF23E17M020 | 18 AWG | 3 | 20 | 65.61 | M/F Extension Set | No Shielding |
| CF23E17M025 | 18 AWG | 3 | 25 | 82.02 | M/F Extension Set | No Shielding |
| CF23E17M030 | 18 AWG | 3 | 30 | 98.42 | M/F Extension Set | No Shielding |
| 64403 | 18 AWG | 4 | 1 | 3.27 | Straight Female Plug | No Shielding |
| 64406 | 18 AWG | 4 | 2 | 6.56 | Straight Female Plug | No Shielding |
| 64412 | 18 AWG | 4 | 4 | 13.08 | Straight Female Plug | No Shielding |
| 64420 | 18 AWG | 4 | 6 | 19.67 | Straight Female Plug | No Shielding |
| CF14C18M010 | 18 AWG | 4 | 10 | 32.8 | Straight Female Plug | No Shielding |
| CF14C18M015 | 18 AWG | 4 | 15 | 49.21 | Straight Female Plug | No Shielding |
| CF14C18M020 | 18 AWG | 4 | 20 | 65.61 | Straight Female Plug | No Shielding |
| CF14C18M025 | 18 AWG | 4 | 25 | 82.02 | Straight Female Plug | No Shielding |
| CF14C18M030 | 18 AWG | 4 | 30 | 98.42 | Straight Female Plug | No Shielding |
| 69403 | 18 AWG | 4 | 1 | 3.27 | 90° Female Plug | No Shielding |
| 69406 | 18 AWG | 4 | 2 | 6.56 | 90° Female Plug | No Shielding |
| 69412 | 18 AWG | 4 | 4 | 13.08 | 90° Female Plug | No Shielding |
| 69420 | 18 AWG | 4 | 6 | 19.67 | 90° Female Plug | No Shielding |
| CF14D18M010 | 18 AWG | 4 | 10 | 32.8 | 90° Female Plug | No Shielding |
| CF14D18M015 | 18 AWG | 4 | 15 | 49.21 | 90° Female Plug | No Shielding |
| CF14D18M020 | 18 AWG | 4 | 20 | 65.61 | 90° Female Plug | No Shielding |
| CF14D18M025 | 18 AWG | 4 | 25 | 82.02 | 90° Female Plug | No Shielding |
| CF14D18M030 | 18 AWG | 4 | 30 | 98.42 | 90° Female Plug | No Shielding |
| 63422 | 18 AWG | 4 | 0.5 | 1.64 | M/F Extension Set | No Shielding |
| 63423 | 18 AWG | 4 | 1 | 3.27 | M/F Extension Set | No Shielding |
| 63426 | 18 AWG | 4 | 2 | 6.56 | M/F Extension Set | No Shielding |
| 63427 | 18 AWG | 4 | 3 | 9.84 | M/F Extension Set | No Shielding |
| 63432 | 18 AWG | 4 | 4 | 13.08 | M/F Extension Set | No Shielding |
| 63433 | 18 AWG | 4 | 5 | 16 | M/F Extension Set | No Shielding |
| 63440 | 18 AWG | 4 | 6 | 19.67 | M/F Extension Set | No Shielding |
| CF24E18M010 | 18 AWG | 4 | 10 | 32.8 | M/F Extension Set | No Shielding |
| CF24E18M015 | 18 AWG | 4 | 15 | 49.21 | M/F Extension Set | No Shielding |
| CF24E18M020 | 18 AWG | 4 | 20 | 65.61 | M/F Extension Set | No Shielding |
| CF24E18M025 | 18 AWG | 4 | 25 | 82.02 | M/F Extension Set | No Shielding |
| CF24E18M030 | 18 AWG | 4 | 30 | 98.42 | M/F Extension Set | No Shielding |
| 63923 | 18 AWG | 4 | 1 | 3.27 | Male 90°/Female Ext. Set | No Shielding |
| 63926 | 18 AWG | 4 | 2 | 6.56 | Male 90°/Female Ext. Set | No Shielding |
| 63932 | 18 AWG | 4 | 4 | 13.08 | Male 90°/Female Ext. Set | No Shielding |
| 69422 | 18 AWG | 4 | 0.5 | 1.64 | Straight Male 90°/Female Ext. Set | No Shielding |
| 69423 | 18 AWG | 4 | 1 | 3.27 | Straight Male 90°/Female Ext. Set | No Shielding |
| 69426 | 18 AWG | 4 | 2 | 6.56 | Straight Male 90°/Female Ext. Set | No Shielding |
| 69427 | 18 AWG | 4 | 3 | 9.84 | Straight Male 90°/Female Ext. Set | No Shielding |
| 69432 | 18 AWG | 4 | 4 | 13.08 | Straight Male 90°/Female Ext. Set | No Shielding |
| 69440 | 18 AWG | 4 | 6 | 19.67 | Straight Male 90°/Female Ext. Set | No Shielding |
| 64503 | 18 AWG | 5 | 1 | 3.27 | Straight Female Plug | No Shielding |
| 64506 | 18 AWG | 5 | 2 | 6.56 | Straight Female Plug | No Shielding |
| 64512 | 18 AWG | 5 | 4 | 13.08 | Straight Female Plug | No Shielding |
| 64520 | 18 AWG | 5 | 6 | 19.67 | Straight Female Plug | No Shielding |
| CF15C19M010 | 18 AWG | 5 | 10 | 32.8 | Straight Female Plug | No Shielding |
| CF15C19M015 | 18 AWG | 5 | 15 | 49.21 | Straight Female Plug | No Shielding |
| CF15C19M020 | 18 AWG | 5 | 20 | 65.61 | Straight Female Plug | No Shielding |
| CF15C19M025 | 18 AWG | 5 | 25 | 82.02 | Straight Female Plug | No Shielding |
| CF15C19M030 | 18 AWG | 5 | 30 | 98.42 | Straight Female Plug | No Shielding |
| 69503 | 18 AWG | 5 | 1 | 3.27 | 90° Female Plug | No Shielding |
| 69506 | 18 AWG | 5 | 2 | 6.56 | 90° Female Plug | No Shielding |
| 69512 | 18 AWG | 5 | 4 | 13.08 | 90° Female Plug | No Shielding |
| 69520 | 18 AWG | 5 | 6 | 19.67 | 90° Female Plug | No Shielding |
| CF15D19M010 | 18 AWG | 5 | 10 | 32.8 | 90° Female Plug | No Shielding |
| CF15D19M015 | 18 AWG | 5 | 15 | 49.21 | 90° Female Plug | No Shielding |
| CF15D19M020 | 18 AWG | 5 | 20 | 65.61 | 90° Female Plug | No Shielding |
| CF15D19M025 | 18 AWG | 5 | 25 | 82.02 | 90° Female Plug | No Shielding |
| CF15D19M030 | 18 AWG | 5 | 30 | 98.42 | 90° Female Plug | No Shielding |
| CF25E19A020 | 18 AWG | 5 | 0.5 | 1.64 | M/F Extension Set | No Shielding |
| 63523 | 18 AWG | 5 | 1 | 3.27 | M/F Extension Set | No Shielding |
| 63526 | 18 AWG | 5 | 2 | 6.56 | M/F Extension Set | No Shielding |
| CF25E19M003 | 18 AWG | 5 | 3 | 9.84 | M/F Extension Set | No Shielding |
| 63532 | 18 AWG | 5 | 4 | 13.08 | M/F Extension Set | No Shielding |
| CF25E19M005 | 18 AWG | 5 | 5 | 16 | M/F Extension Set | No Shielding |
| 63540 | 18 AWG | 5 | 6 | 19.67 | M/F Extension Set | No Shielding |
| CF25E19M010 | 18 AWG | 5 | 10 | 32.8 | M/F Extension Set | No Shielding |
| CF25E19M015 | 18 AWG | 5 | 15 | 49.21 | M/F Extension Set | No Shielding |
| CF25E19M020 | 18 AWG | 5 | 20 | 65.61 | M/F Extension Set | No Shielding |
| CF25E19M025 | 18 AWG | 5 | 25 | 82.02 | M/F Extension Set | No Shielding |
| CF25E19M030 | 18 AWG | 5 | 30 | 98.42 | M/F Extension Set | No Shielding |
| CF18C60M001 | 22 AWG | 8 | 1 | 3.27 | Straight Female Plug | No Shielding |
| CF18C60M002 | 22 AWG | 8 | 2 | 6.56 | Straight Female Plug | No Shielding |
| CF18C60M004 | 22 AWG | 8 | 4 | 13.08 | Straight Female Plug | No Shielding |
| CF18C60M006 | 22 AWG | 8 | 6 | 19.67 | Straight Female Plug | No Shielding |
| CF18C60M010 | 22 AWG | 8 | 10 | 32.8 | Straight Female Plug | No Shielding |
| CF18C60M015 | 22 AWG | 8 | 15 | 49.21 | Straight Female Plug | No Shielding |
| CF18C60M020 | 22 AWG | 8 | 20 | 65.61 | Straight Female Plug | No Shielding |
| CF18C60M025 | 22 AWG | 8 | 25 | 82.02 | Straight Female Plug | No Shielding |
| CF18C60M030 | 22 AWG | 8 | 30 | 98.42 | Straight Female Plug | No Shielding |
| CF18D60M001 | 22 AWG | 8 | 1 | 3.27 | 90° Female Plug | No Shielding |
| CF18D60M002 | 22 AWG | 8 | 2 | 6.56 | 90° Female Plug | No Shielding |
| CF18D60M004 | 22 AWG | 8 | 4 | 13.08 | 90° Female Plug | No Shielding |
| CF18D60M006 | 22 AWG | 8 | 6 | 19.67 | 90° Female Plug | No Shielding |
| CF18D60M010 | 22 AWG | 8 | 10 | 32.8 | 90° Female Plug | No Shielding |
| CF18D60M015 | 22 AWG | 8 | 15 | 49.21 | 90° Female Plug | No Shielding |
| CF18D60M020 | 22 AWG | 8 | 20 | 65.61 | 90° Female Plug | No Shielding |
| CF18D60M025 | 22 AWG | 8 | 25 | 82.02 | 90° Female Plug | No Shielding |
| CF18D60M030 | 22 AWG | 8 | 30 | 98.42 | 90° Female Plug | No Shielding |
| CF28E60A020 | 22 AWG | 8 | 0.5 | 1.64 | M/F Extension Set | No Shielding |
| CF28E60M001 | 22 AWG | 8 | 1 | 3.27 | M/F Extension Set | No Shielding |
| CF28E60M002 | 22 AWG | 8 | 2 | 6.56 | M/F Extension Set | No Shielding |
| CF28E60M003 | 22 AWG | 8 | 3 | 9.84 | M/F Extension Set | No Shielding |
| CF28E60M004 | 22 AWG | 8 | 4 | 13.08 | M/F Extension Set | No Shielding |
| CF28E60M005 | 22 AWG | 8 | 5 | 16 | M/F Extension Set | No Shielding |
| CF28E60M006 | 22 AWG | 8 | 6 | 19.67 | M/F Extension Set | No Shielding |
| CF28E60M010 | 22 AWG | 8 | 10 | 32.8 | M/F Extension Set | No Shielding |
| CF28E60M015 | 22 AWG | 8 | 15 | 49.21 | M/F Extension Set | No Shielding |
| CF28E60M020 | 22 AWG | 8 | 20 | 65.61 | M/F Extension Set | No Shielding |
| CF28E60M025 | 22 AWG | 8 | 25 | 82.02 | M/F Extension Set | No Shielding |
| CF28E60M030 | 22 AWG | 8 | 30 | 98.42 | M/F Extension Set | No Shielding |
| CF18C61M001 | 22 AWG | 8 | 1 | 3.27 | Straight Female Plug | Overall Shield |
| CF18C61M002 | 22 AWG | 8 | 2 | 6.56 | Straight Female Plug | Overall Shield |
| CF18C61M004 | 22 AWG | 8 | 4 | 13.08 | Straight Female Plug | Overall Shield |
| CF18C61M006 | 22 AWG | 8 | 6 | 19.67 | Straight Female Plug | Overall Shield |
| CF18C61M010 | 22 AWG | 8 | 10 | 32.8 | Straight Female Plug | Overall Shield |
| CF18C61M015 | 22 AWG | 8 | 15 | 49.21 | Straight Female Plug | Overall Shield |
| CF18C61M020 | 22 AWG | 8 | 20 | 65.61 | Straight Female Plug | Overall Shield |
| CF18C61M025 | 22 AWG | 8 | 25 | 82.02 | Straight Female Plug | Overall Shield |
| CF18C61M030 | 22 AWG | 8 | 30 | 98.42 | Straight Female Plug | Overall Shield |
| CF18D61M001 | 22 AWG | 8 | 1 | 3.27 | 90° Female Plug | Overall Shield |
| CF18D61M002 | 22 AWG | 8 | 2 | 6.56 | 90° Female Plug | Overall Shield |
| CF18D61M004 | 22 AWG | 8 | 4 | 13.08 | 90° Female Plug | Overall Shield |
| CF18D61M006 | 22 AWG | 8 | 6 | 19.67 | 90° Female Plug | Overall Shield |
| CF18D61M010 | 22 AWG | 8 | 10 | 32.8 | 90° Female Plug | Overall Shield |
| CF18D61M015 | 22 AWG | 8 | 15 | 49.21 | 90° Female Plug | Overall Shield |
| CF18D61M020 | 22 AWG | 8 | 20 | 65.61 | 90° Female Plug | Overall Shield |
| CF18D61M025 | 22 AWG | 8 | 25 | 82.02 | 90° Female Plug | Overall Shield |
| CF18D61M030 | 22 AWG | 8 | 30 | 98.42 | 90° Female Plug | Overall Shield |
| CF28E61A020 | 22 AWG | 8 | 0.5 | 1.64 | M/F Extension Set | Overall Shield |
| CF28E61M001 | 22 AWG | 8 | 1 | 3.27 | M/F Extension Set | Overall Shield |
| CF28E61M002 | 22 AWG | 8 | 2 | 6.56 | M/F Extension Set | Overall Shield |
| CF28E61M003 | 22 AWG | 8 | 3 | 9.84 | M/F Extension Set | Overall Shield |
| CF28E61M004 | 22 AWG | 8 | 4 | 13.08 | M/F Extension Set | Overall Shield |
| CF28E61M005 | 22 AWG | 8 | 5 | 16 | M/F Extension Set | Overall Shield |
| CF28E61M006 | 22 AWG | 8 | 6 | 19.67 | M/F Extension Set | Overall Shield |
| CF28E61M010 | 22 AWG | 8 | 10 | 32.8 | M/F Extension Set | Overall Shield |
| CF28E61M015 | 22 AWG | 8 | 15 | 49.21 | M/F Extension Set | Overall Shield |
| CF28E61M020 | 22 AWG | 8 | 20 | 65.61 | M/F Extension Set | Overall Shield |
| CF28E61M025 | 22 AWG | 8 | 25 | 82.02 | M/F Extension Set | Overall Shield |
| CF28E61M030 | 22 AWG | 8 | 30 | 98.42 | M/F Extension Set | Overall Shield |
| Cable Part No. | Conductor Size (AWG) | Conductor/Pole Count | Stranding | Nominal O.D. inches |
WT. Per 1000' lbs |
Shielding Type |
|---|---|---|---|---|---|---|
| 62022 | 18 AWG | 2 | 41/34 | 0.22 | 31 | Unshielded |
| 62023 | 18 AWG | 3 | 41/34 | 0.22 | 35.1 | Unshielded |
| 62024 | 18 AWG | 4 | 41/34 | 0.24 | 41.5 | Unshielded |
| 62025 | 18 AWG | 5 | 41/34 | 0.255 | 50.3 | Unshielded |
| 62003 | 18 AWG | 3 | 19/30 | 0.26 | 60 | Shielded |
| 62004 | 18 AWG | 4 | 19/30 | 0.285 | 65 | Shielded |
| 62005 | 18 AWG | 5 | 19/30 | 0.31 | 70 | Shielded |
| 62033 | 22 AWG | 3 | 7/30 | 0.175 | 31 | Unshielded |
| 62034 | 22 AWG | 4 | 7/30 | 0.184 | 37 | Unshielded |
| 62035 | 22 AWG | 5 | 7/30 | 0.203 | 47 | Unshielded |
| 60018 | 22 AWG | 8 | 7/30 | 0.245 | 32.6 | Unshielded |
| 60019 | 22 AWG | 8 | 7/30 | 0.28 | 59.6 | Shielded |
