Thermo-Trex® Heavy-Duty Blue Silicone Fiberglass High Temp Ultra-Sleeve

Heavy-Duty Blue Silicone Fiberglass Ultra-Sleeve High Temperature Sleeving is a protective sleeve constructed of heavy E-glass continuous yarn with an increased 30% wall thickness for extreme high heat environments. Ideal for protecting cables, hoses and pipes from flash heat or flame, chemical or mechanical abuse. This Ultra-Sleeve offers heat resistance up to 260°C and excellent protection against moisture and chemicals. Also available with Hook and Loop closure for easy installation.

Request a Quote Download Spec Sheet
Features
Resources
Ratings
Applications
Part Numbers
Related Products

Features

Finely Stranded Spun Glass Fiber Inner Sleeve

Finer strands allow for greater flexibility. Higher density of glass fibers per square inch increases cable protection. 30% thicker than traditional Silicone Fiberglass sleeves.

Extra Thick Silicone Rubber Outer Sleeve

Provides a first line of defense against heat, flame, molten metal splash, abrasion, and chemicals.

High Temperature Properties

Suitable for continuous use at 260°C and intermittent use up to 1093°C. Offers superior protection for cables, assemblies, hoses, and pipes.

Available in Multiple Diameters

Allows for selection of the right size sleeve for the application. Protects most cable & hose sizes.

Suitable for Indoor and Outdoor Use

Resistant to most fluids including petroleum-based chemicals.

Available With & Without Closure

Optional Hook and Loop Closure allows for quick field installation and removal of sleeve.

Resources

Specsheets

Product Overview

Ratings / Characteristics

  • Continuous Temperature Range -54°C to 260°C / -65°F to 500°F

  • Intermittent Temperature Up to 1093°C / 2000°F for 15-20 minutes

  • Flame Resistance: Very Good

  • Weld Spatter Resistance: Excellent

  • Molten Splash Resistance: Outstanding

  • Flexibility: Very Good

  • Abrasion Resistance: Very Good

  • Water and Oil Resistance: Outstanding

Applications

heat-icon

Extreme Temperature

chemicals-icon

Chemicals

flexing-icon

Flexing

abrasions-icon

Abrasion

Part Numbers

Part No. Inner Diameter
Inch		 With Hook & Loop Closure
49116 1/2 No
49117 3/4 No
49118 1 No
49120 1-1/2 No
49121 1-3/4 No
49122 2 No
49123 2-1/2 No
49124 3 No
49125 3-1/2 No
49150 1/2 Yes
49151 3/4 Yes
49152 1 Yes
49156 1-1/2 Yes
49157 1-3/4 Yes
49158 2 Yes
49159 2-1/2 Yes
49160 3 Yes
49161 1-3/2 Yes
