Thermo-Trex® 600-Plus Silicone Cable

Thermo-Trex® 600-Plus Silicone Cable is a high-temperature cable for power and control applications that can withstand a maximum conductor temperature of 200°C / 392°F. Thermo-Trex 600-Plus also features a smaller diameter than traditional silicone jacketed cables to be used in areas with restricted space.

This flexible control and instrumentation cable features finely stranded nickel-plated copper conductors and a silicone jacket. It is ideal for use in industrial applications where exposures to high temperatures and where oils, coolants, water and grease are prevalent.

Features

FINELY STRANDED NICKEL PLATED TINNED COPPER CONDUCTORS

Offers improved flexibility in dynamic applications and protection from corrosion and oxidation in chemical and high temperature environments.

FLUOROPOLYMER INSULATION

Extremely chemical resistant and mechanically durable for additional protection against cutting and abrasion. Conductors slide easily within insulation for maximum flex life.

TEAR RESISTANT SILICONE JACKET

Provides excellent protection against abrasion, mechanical abuse and resistance to moisture, oils and basic industrial fluids. Resistant to high temperatures and remains flexible down to -40°C.

Resources

Specsheets

Product Overview

Resource-Color Code

Thermo-Trex® 600-Plus Silicone Cable

Ratings / Characteristics

  • UL Recognized

  • CSA

  • FT-2 Flame Rating

  • 600 V

  • Max Conductor Temperature 200°C

  • Cold Temperature Rating -40°C

Applications

heat-icon

Extreme Temperature

flexing-icon

Flexing

chemicals-icon

Chemicals

Part Numbers

Part No. Conductor Size Conductor Pole Count STRANDING AMPACITY NOMINAL O.D.
INCHES
WT. PER 1000'
lbs
Shielding Type
41683 18 AWG 3 41/34 21 0.256 44 No Shielding
41684 18 AWG 4 41/34 21 0.275 53 No Shielding
41685 18 AWG 5 41/34 16 0.297 62 No Shielding

Request a Quote
