Super-Trex® 4/0 Type TC Power Cable

Super-Trex® 4/0 Type TC Power Cables are designed with a double pass TSE fiber-reinforced jacket which provides excellent resistance to impact, abrasion, oils and most industrial chemicals while providing added strength against twisting and pulling.

The security yellow TSE jacket provides excellent protection against pulling and twisting and allows for extreme all-weather flexibility.

Features

Bunch Stranded Soft Drawn Copper

Longer flex life in flexing and twisting applications.

Conductors Are Numbered

Provides fast identification of conductors. Easy to read and simplifies installation.

Live-flex FREP Conductor Insulation

Flame retardant EP insulation designed for tray cable applications. High dielectric, tensile and mechanical properties.

Rayon Tire Cord Reinforcing Braid Embedded in Jacket

Provides added strength. Improves cable resistance to impact, abrasion, twisting and pulling.

Black Heavy-duty Super-Trex® TSE Double Pass Jacket

Provides superior first line defense against industrial and environmental abuse. Resists tearing, abrasion, oil, impact, ozone and most chemicals. Flame and heat resistant. Extreme all weather flexibility.

Resources

Specsheets

Product Overview

Ratings / Characteristics

  • UL Listed

  • CSA

  • Type TC-ER –600 V

  • Suitable forClass II,II, Division 2

  • UV Resistant

  • RoHS Compliant

  • Max Conductor Temperature 90°C

  • FT-4

Applications

abrasions-icon

Abrasion

chemicals-icon

Chemicals

flexing-icon

Flexing

impact-icon

Impact

tension-icon

Tension

Part Numbers

Part No. CABLE SIZE AWG/COND Cond. Stranding Ampacity NOMINAL O.D.
inches
WT. PER 1000'
lbs
MIN. BEND RADIUS
inches
85412 4/0 - 2 Conductor with a 1/0 Ground 2090 x 30 & 1064 x 30 260 1.79 2958 14.32
85413 4/0 - 3 Conductor with a 1/0 Ground 2090 x 30 & 1064 x 30 260 2.16 4170 17.28
